WireStripper-InsulationRemovingTool

Descrição

Download this STL Model for made by Lamblab. Need a tool to help remove insulation from wires before scrapping? try this one! blade is adjustable to accommodate different wire sizes. additional parts needed: 1x Utility Blade 3x M3x10 socket head Screws 3x M3 nuts Steps for use: 1. adjust blade to fit your target wire for stripping, the blade should dig into the insulation but not the copper. 2. place the start of the wire in the v slot and carefully pull the first few inches through 3. once you have the wire started, hold the wire in the same hand as the tool so that the wire is touching the knife edge 4. with your free hand pull the wire through once you've scored the entire length of wire, separate the copper from the insulation. I typically place the copper in a table vice and pull the insulation away.
